MRD5016 Topline - ROGI Radial drilling machine

MRD5016 Topline - ROGI Radial drilling machine

Contact us for price

Location:Mierlo, Netherlands

or
Call +31492599593

Description

Ground and hardened guideways T-slotted box table Arm elevation via screw and motor

Full hydraulic clamping

Automatic lubrication system Coolant system LED working lamp Fixing bolts Reducing sleeves MT5-4, MT4-3, MT3-2

SCHNEIDER electric CE plug

Show All

Specifications

ManufacturerROGI
ModelMRD5016 Topline
ConditionNew
Stock NumberD3502
Drilling capacity50 mm
Tapping capacityM42
Spindle - Column distance350 - 1600 mm
Column diameter350 mm
Spindle taperMT5
Spindle stroke315 mm
Spindle speed range25 - 2000 rpm (16)
Spindle feed range0.04 - 3.2 mm/rev (16)
Spindle - Table distance350 - 1220 mm
Worktable dimension630 x 500 x 500 mm
Base size2400 x 1000 x 200 mm
Motor4 kW
Power supply400 V / 50 Hz
Weight3500 kg
Dimensions L x W x H2500 x 1070 x 2840 mm
