WM180V - ROGI Lathe

WM180V - ROGI Lathe

Contact us for price

Mierlo, Netherlands

orCall +31492599593

Description

Two speed bands allow maximum torque in the lower speeds Infinitely variable from 0-2500 rpm Double vee bedway - hardened and ground Adjustable gibs to slideways Off set facility to tailstock Tailstock quill engraved metric and imperial Reversible motor Metric and imperial thread cutting Zero friction dials Steel gears Powerful 600W motor Fitted with taper roller bearings


Standard Accessories 3-jaw chuck 100 mm Splash guard Chip tray Change gears Toolbox & tools


Options 4-jaw chuck 100 mm Backplate Faceplate 175 mm Steady rest Follow rest Threading dial Multifix toolpost A0 Stand

Specifications

ManufacturerRogi
ModelWM180V
ConditionNew
Item NoWM180V
Centre height90 mm
Swing over bed180 mm
Swing over cross slide110 mm
Distance between centres300 mm
Bed width100 mm
Spindle taperMT3
Spindle bore21 mm
Range of spindle speeds0 - 2500 rpm
Range of metric threads0.5 - 3 mm
Range of imperial threads10 - 44 tpi
Tailstock taperMT2
Tailstock quill travel60 mm
Longitudinal travel280 mm
Top slide travel55 mm
Cross slide travel75 mm
Compound slide swivel45º
Chuck mountingFlange fitting
Motor600W
Power supply230V-1PH-50HZ
Maximum tool size10 mm
Packing size L x W x H800 x 480 x 460 mm
Weight60 kg
