MRD4010 - ROGI Radial Drilling Machine
MRD4010 - ROGI Radial Drilling Machine
Contattaci per il prezzo
Posizione:Mierlo, Paesi Bassi
o
Chiama +31492599593
Descrizione
Ground and hardened guideways
T-slotted box table
Arm elevation via screw and motor
Coolant system
LED working lamp
SCHNEIDER electric components
Fixing bolts
Reducing sleeves MT4-3, MT4-2, MT3-1
CE plug
Specifiche
| Produttore | ROGI |
| Modello | MRD4010 |
| Anno | 2026 |
| Condizione | Nuovo |
| Numero di magazzino | 656493 |
| Drilling capacity | 40 mm |
| Distance from spindle axis to column | 320 - 1020 mm |
| Diameter of column | 200 mm |
| Spindle taper | MT4 |
| Spindle stroke | 240 mm |
| Range of spindle speeds | (6) 75 - 1220 rpm |
| Range of spindle feeds | (3) 0.10 - 0.25 mm/rev |
| Distance from spindle nose to base | 120 - 860 mm |
| Dimension of worktable | 400 x 400 x 350 mm |
| Base size | 1370 x 700 x 160 mm |
| Motor | 1.5 kW |
| Power supply | 400 V / 50 Hz |
| Weight | 1310 kg |
| Machine dimension | 1600 x 720 x 1885 mm |
